Light Measurement Instrumentation

Calibrated equipment for measuring a variety of light sources

Spectroradiometers
• ILT950/950UV – high sensitivity, high resolution (<2 nm) spectroradiometer. Broadband (250-1050
nm) and UV only (200-450 nm) models.
• ILT550/550V – lower cost, lower resolution broadband (250-950 nm) or visible (360-850 nm)
spectroradiometer.
All spectroradiometers are provided with the ILT SpectriLight III software, which can be used to measure
irradiance/illuminance, photopic/radiometric power, radiance/luminance, PAR, CCT etc (calibrations and
additional hardware required where applicable).

Belt radiometers
• ILT1400/490 – UV profiling belt radiometers. Includes measurement of peak irradiance, integrated
exposure and intensity profiling.

Features: LIGHT & LASERS
• Graphical display for quick identification of faulty lamps
2
2
2
2
• 5 mW/cm to 20 W/cm measurement range (5 mJ/cm – 20 J/cm )
• Built-in rechargeable batteries (charger included)
• Storage of baseline reading for reference
• Suitable for belt speeds of 1-80 feet per minute
Lux meter
• ILT10 – low cost lux meter. Hand-held, battery powered, 400-700 nm, 10-400,000 lux range, 0.1 lux
resolution, 4 digit LCD display, data hold, over/under range indicator, max/min reading. Optional
NIST traceable calibration.
42
